Machine feathures:
1) Optional working table - Honeycomb, strip, conveyor different size working table for choice, depending on your material.
2) Optional laser source - 60-150w CO2 Glass sealed laser tube China famous brand (EFR, Reci), good beam mode stability, service time over 8500~10000 working hours.
3) Imported hardware - US top brand II VI with less energy loss, high reflectivity, strong focusing and durable. South Korea linear guide and belt ensure the high accuracy transmission.
4) Excellent standard accessories - Industrial water cooling system, exhausting fans and air blow pump bring perfect cutting edge and clean environment. Also, they will make your machine working long time.
5) Professional software -It is compatible with CAD, BMP, CorelDraw, DST, PLT and other related software. Get free upgrades of the software.
Machine parameter :
Model | FW6090 | FW1390 | FW1610 | FW1810 | FW1612 | FW1813 | customized size |
Working table | Honeycomb, strip and conveyor table for choice | ||||||
Working area | 0.6*0.9m | 1.3*0.9m | 1.6*1m | 1.8*1m | 1.6*1.2m | 1.8*1.3m | |
Laser head | Single head | Double heads | 4heads | ||||
Laser power | 60/80/100/130/150w CO2 glass laser tube | ||||||
Engraving Speed | 0-60000mm/min | ||||||
Cutting speed | 0-40000mm/min | ||||||
Laser Power Control | 0-100%Manual Adjustment and software controlling | ||||||
Motion System | Hydird servo motor | ||||||
Repeat location Accuracy | +/-0.01mm | ||||||
Voltage | 110V/220V 50HZ/60HZ | ||||||
Cooling System | Industrial water chiller CW3000 or CW5200 | ||||||
User control | Digital Screen Panel | ||||||
Operate system | Windows XP/7/8 | ||||||
Format Support | AI/DXF/DWG/JPG/BMP/PLT/DST CorelDraw/Photoshop/AutoCAD/Illustrator | ||||||
Software | CamMech LasCut Composer | ||||||
Machine spare part :
