Raycus IPG JPT Color Mopa 20W 30W 50W Portable Fiber Laser Marking Machines

Raycus IPG JPT Color Mopa 20W 30W 50W Portable Fiber Laser Marking Machines

Product Tags : Fiber laser marking machine

Product Attributes :

1. High quality laser path suitable for delicate marking. Reaching nearest to the limit of diffraction.
2. High pulse repeating rate and stable power bring high speed laser marking.
3. High speed 2-3 times over than traditional diode pumped marking machine.
4. Air-cooling smart machine size!
5. Long lifetime. Ultra-low power consumption of 0.5 kw. Efficiency conversion reach to over 30%
6.Suitable for various fiber laser generators.

Product Description

Specification

Laser power	10W/20W/30W/50W/option
Laser wave length	1064nm
Sandard marking area	200*200mm
Optional marking area	100100 , 300300 customerized aviliable
Minimum character	0.15mm
Marking speed	≤7000mm/s
Marking depth	0.01~1mm
Repeat frequency	20KHZ~80KHZ
Output laser beam	M²≤2
Focus spot diameter	< 0.01mm
Control interface	Standard USB port
Graphic format supported	BMP,JPG,AI,PLT,DST,DWG ETC.
Marking format	Text,symbols,graphics,images,barcodes,two-dimension bar. date marking,batch number,serial number etc.
Operating temperature	0-45°C
Cooling way	Built-fan for air cooling
Working voltage	220V-50Hz(single phase)or 110V-60Hx(single phase)
Computer	Including laptop cpmputer per set(software installed)
Laser marking oftware	Ezcad(English version)(the other optional software please contact us)
General power	<0.5KW
Working environment	Clean and dust-free or dust less
Working condition	5%~75%,free of condensed water
Optional device	Rotary marking attachment ;X/Y adjustable table, Mopa color marking
