FW1625 vibration knife cutting machine for leather

FW1625 vibration knife cutting machine for leather

Product Attributes :

1)Cutting Angle v-shaped cutting system can cut Angle 45 °, 30 ° and 22.5 °, 15 °, 0 °, 5 kinds of different angles of V groove.

2)Cutting material:can cut the honeycomb cardboard, corrugated paper and plastic corrugated board, grey board paper, white cardboard, cloth, plastic board, pearl cotton foam and KT board, and other materials

Product Description

Machine parameter :

Model	FW 1208	FW 1311	FW 1713	FW 2511
Cutting range	1200mm×800mm	1300mm×1100mm	1700mm×1300mm	2500mm×1100mm
Length	800mm-3200mm
Width	800mm-3200mm
Max Cutting speed	1800mm /s
Thickness	25mm
Motor	Imported servo motor
Frequency of shock	Vibration motor18000 RPM/min
Fixed way	Intelligent vacuum adsorption
Precision	0.1mm
Transmission interface	Standard parallel port, serial port, internet access
Numerical control panel	Liquid crystal display and contact key-switch
Working Voltage	Alternating current 110v ± 22v/50HZ 220v ± 22v/50HZ 380v ± 22v/50HZ
Working frequency	50±1Hz ,60±1Hz
Working Voltage of air pump	Alternating current 380v ± 38v
Pump power	4KW	4KW	7.5KW	7.5KW
Transmitting material	Taiwan linear guide, import synchronous belt
Identify the format	DXF,HPGL
Working characteristic	Computer operation and cutting machine simultaneously, in order to realize data transmission quickly.
